SB-Acoustics SB34NRX75-6 / Norex

FEATURES:

• High flow venting center pole
• 3" voice coil
• Low dampening surround
• Non-inductive voice coil former
• Proprietary cone materials made-in-house
• Cast Aluminium chassis

SPECS:

• Nominal Impedance 6 Ω
• DC resistance, Re 4.2 Ω
• Voice coil inductance, Le 1.8 mH
• Effective piston area, Sd 508 cm²
• Voice coil diameter 75.6 mm
• Voice coil height 28 mm
• Air gap height 6 mm
• Linear coil travel (p-p) 22 mm
• Magnetic flux density 0.9 T
• Magnet weight 2.1 kg
• Net weight 6.02 kg
• Free air resonance, Fs 19 Hz
• Sensitivity (2.83V/1m) 90 dB
• Mechanical Q-factor, Qms 5.1
• Electrical Q-factor, Qes 0.43
• Total Q-factor, Qts 0.40
• Moving mass incl. air,Mms 99 g
• Force factor, Bl 10.7 Tm
• Equivalent volume, Vas 260 liters
• Compliance, Cms 0.71 mm/N
• Mechanical loss, Rms 2.3 kg/s
• Rated power handling* 200 W

* IEC 268-5, T/S parameters measured on drive units that are broken in.

Je kunt alle uitgebreide technische gegevens vinden op het datablad, download dan onze PDF
