SB-ACOUSTICS SB14ST-C000-4 / Fabric

FEATURES

• Very compact design
• Excellent piston diameter to OD ratio
• Large surround for smooth dispersion
• Threaded rear center hole for easy mounting
• Long insulated lead wires for versatile integration

SPECS

• Nominal Impedance 4 Ω
• DC resistance, Re 3.0 Ω
• Voice coil inductance, Le – mH
• Effective piston area, Sd – cm2
• Voice coil diameter 12.4 mm
• Voice coil height 1.2 mm
• Air gap height 1.5 mm
• Linear coil travel (p-p) 0.3 mm
• moving mass incl. air, Mms -
• Free air resonance, Fs 1300 Hz
• Sensitivity (2.83V/1m) 87 dB
• Mechanical Q-factor, Qms –
• Electrical Q-factor, Qes –
• Total Q-factor, Qts –
• Force factor, Bl – Tm
• Rated power handling* 10 W
• Magnetic flux density 0.97 T
• Magnet weight 3.4 g
• Net weight 0.014 kg

*IEC 268-5, high-pass Butterworth, 2600 Hz, 12 dB/oct

je kunt alle uitgebreide technische gegevens vinden op het datablad, download dan onze PDF
