SB-Acoustics SB26SFCL38-8

FEATURES:

• Hard pressed vented paper cone
• Durable rubber surround
• Symmetric suspension
• Non-conductive coil former
• Long life litz wires
• Vented chassis
• Bucking magnet

SPECS:

• Nominal Impedance 8 Ω
• DC resistance, Re 6 Ω
• Voice coil inductance, Le 1.6 mH
• Effective piston area, Sd 346 cm²
• Voice coil diameter 38.5 mm
• Voice coil height 22.4 mm
• Air gap height 6 mm
• Linear coil travel (p-p) 16.4 mm
• Magnetic flux density 1.05 T
• Magnet weight 1.1 kg
• Net weight 2.9 kg
• Free air resonance, Fs 27.5 Hz
• Sensitivity (2.83V/1m) 88 dB
• Mechanical Q-factor, Qms 5.09
• Electrical Q-factor, Qes 0.60
• Total Q-factor, Qts 0.53
• Moving mass incl. air,Mms 53 g
• Force factor, Bl 9.6 Tm
• Equivalent volume, Vas 107 liters
• Compliance, Cms 0.63 mm/N
• Rated power handling* 80 W

* IEC 268-5, T/S parameters measured on drive units that are broken in.

Je kunt alle uitgebreide technische gegevens vinden op het datablad, download dan onze PDF
