SB-Acoustics MW19TX-8 TeXtreme

FEATURES

• Advanced TeXtreme® cone
• Vented aerodynamic cast aluminium chassis
• Soft low damping rubber surround
• Advanced BIMAX spider
• Powerful optimized low distortion neodymium motor system
• Extended copper sleeve on pole piece
• Non-conducting fiberglass voice coil former
• Vented pole piece and voice coil
• Light weight CCAW voice coil
• Long life silver lead wires

SPECS

• Nominal Impedance 8 Ω
• DC resistance, Re 6.0 Ω
• Voice coil inductance, Le 0.20 mH
• Effective piston area, Sd 158 cm²
• Voice coil diameter 39 mm
• Voice coil height 19.4 mm
• Air gap height 6 mm
• Linear coil travel (p-p) 13.4 mm
• Magnetic flux density 1.1 T
• Magnet weight 0.15 kg
• Net weight 1.46 kg
• Free air resonance, Fs 33 Hz
• Sensitivity (2.83V/1m) 90 dB
• Mechanical Q-factor, Qms 6.47
• Electrical Q-factor, Qes 0.35
• Total Q-factor, Qts 0.33
• Moving mass incl. air,Mms 15.6 g
• Force factor, Bl 7.5 Tm
• Equivalent volume, Vas 53.4 liters
• Compliance, Cms 1.52 mm/N
• Mechanical loss, Rms 0.5 kg/s
• Rated power handling* 70 W

Je kunt alle uitgebreide technische gegevens vinden op het datablad, download dan onze PDF
